CH-CM0206 Auto-Cut

Rush Machinery Auto-Cut
  • Description
  • The CNC Auto-Cut Cut-Off Machine automatically cuts carbide rod into precision lengths. This production machine, designed for cutting tool manufacturers and carbide rod processors, has a large capacity magazine and an automatic loader to allow for hours of unattended operation.
  •
  • The Auto-Cut can double the production rate for cutting carbide and hardened steel rod when compared with manual cut-off
    machines. It has easy to use CNC controls with a touch screen operator interface. Parameters can be quickly set for rod diameter and length.
  •
  • Capacity of the Auto-Cut is 0.055” (1.4 mm) to 1.575” (40 mm) diameter rod, length capacity 3.150″ (80 mm) to 16.535″ (420 mm), and comes standard with a flood coolant system.
  •
  •
Machine Features
  • –  Easy to use CNC Control with touch pad operator interface

  • –  Parameters easily set for rod diameter, length, etc.

  • –  Automatically loads and cuts bars from large capacity magazine
  •
  • –  5 HP spindle motor
  •
  • –  Clamps bar stock on each side of the cut-off wheel
  •
  • –  Automatically compensates for wheel wear
  •
  • –  Diamond cut-off wheel
  •
  • –  Magazine insert for use with large diameter rods
  •
  • –  Machine setup and training by Rush Machinery personnel
  •
  • –  Detailed operator manual
  •
  • –  Flood coolant system
  •
  • –  Catch basket with cushioning rubber mat

Optional Accessories
  • –  30 Gallon Coolant System – two stage filter with 40-micron paper filter roll with 5-micron filter bag
  •
  • –  Mist Collection – high efficiency air filtration up to 97% on submicron particles
  •
  • –  Fire Suppression System (required when using oil as flood coolant)
